MB® 7 bbl Brewhouse | Mash Rake & Plow System | Electric Oversized HLT | Insulated Mash Tun | Electric Boil Kettle | T.C. Sanitary Ports | All Fittings Included | Passivated Ready to Use | American Engineered | Ships from USA
Login to view pricing
PBE0007RP-MB

MB® 7 bbl Brewhouse | Mash Rake & Plow System | Electric Oversized HLT | Insulated Mash Tun | Electric Boil Kettle | T.C. Sanitary Ports | All Fittings Included | Passivated Ready to Use | American Engineered | Ships from USA

Login to view pricing
Description

  • Complete electric brewhouse with electric boil kettle & hot liquor tank and insulated mash tun
  • Boil kettle features a tangential whirlpool port, myrcene ring to keep flue condensation from entering the boil, glass manway door, and insulated walls for heating efficiency
  • Oversized HLT large enough for mashing and sparging without needing to top off. Features sight gauge and tapered bottom with center drain
  • Insulated mash tun with rake & plow system features a slotted 3-piece false bottom, adjustable height sparge arm, and large grain out manway door with removable chute
  • All tanks ship domestically from within the contiguous United States

The MB Pro Brewhouse features an Electric Boil Kettle, Electric Hot Liquor Tank, and Insulated Mash Tun—all perfectly sized for 7 bbl batches. MB Pro Brewing Systems are very well constructed and represent an amazing overall value. They also boast a very impressive feature set.

Great Quality from MB
Our brewing systems are made at a family owned manufacturer in the Ningbo region of China. Ningbo is where most premium beer tanks and brewing vessels come from and represents a known style and level of quality when compared to other areas of China. Our professional brewhouse equipment is designed by our in-house R&D designer Colin Kaminski, a former brewmaster for 15 years. Cleanability, ease of use, and durability are our primary design criteria. Our manufacturing partner in China is a father/son team that takes great pride in what they do. Some discount dealers buy from different manufacturers who offer one-off deals. That can be fine one time but not the next.

Great Value from MoreBeer! Pro
If you used MoreBeer! as a homebrewer, you may not know that MoreBeer! & MoreBeer! Pro combined is one of the largest brewing supply companies in the world with over 250,000 customers. We’ve seen countless homebrewers turn pro, and there’s nothing that makes us happier than being a part of that transition. As a privately owned brewing supply company that's been in business for over 25 years, we’ve established relationships with suppliers and manufacturers around the world and at every level of the industry. We get a great price and we pass that on to you.

Please Note: the electric boil kettle and hot liquor tank are supplied without controls for the electric elements.

Electric Boil Kettle
Our Pro Electric Boil Kettle features three 15,000W heating elements, dedicated tangential whirlpool port, condensation ring, and a host of other key features guaranteed to satisfy the expectations of today's pro brewer.

Boil Kettle Features:
  • Insulated walls for safety and energy efficiency
  • Condensation ring to keep flue condensation from entering the boil (Myrcene Ring)
  • Tangential port for whirlpool
  • Side drain with hop dam for easy whirlpooling and good trub separation
  • Dished bottom with 2" center drain for easy trub clean up
  • Fill Port for adding dilution water
  • Float Switch to protect the electric elements from running dry (wiring required)
  • Powered by (3) 15,000-watt 3-phase 208V elements
  • Total Amperage Draw: 125 amps at 3ph 208V
  • The kettle must be grounded
  • PT100 Temp Sender
  • Analog Temp Gauge for quick reading
  • CIP Ball
  • Glass Manway Door
  • Internal LED Light

Boil Kettle Specifications:

  • Grade 304 Stainless Steel
  • Internal Finish: #2B
  • Tank Height: 71"
  • Tank Diameter: 50"
  • Empty Weight: 705 lbs
  • Working Volume: 7 bbl
  • Max Volume: 9.9 bbl
  • All ports are 1.5" TC except for DN400 Manway, DN219 Vent Port, DN80 LED Light Port, 2" TC Drain Outlet, 2" TC Element Ports

Electric Hot Liquor Tank
Our Pro Electric Hot Liquor Tank features three 15,000W heating elements, insulated walls for energy efficiency, condensation ring, and a host of other key features guaranteed to satisfy the expectations of today's pro brewer. A float switch is pre-installed just above the heating elements, which is intended to protect your elements from running dry. The device comes unwired and needs to be included in a circuit in order to function.

HLT Features:
  • Oversized to allow mashing and sparging without having to top off
  • Insulated walls for safety and energy efficiency
  • Condensation Trap so no flue is used
  • Sight Gauge to check volume
  • Fill Port
  • Tapered Bottom w/ Center Drain
  • Float Switch to protect the electric elements from running dry (wiring required)
  • Powered by (3) 15,000-watt 3-phase 208V elements
  • Total Amperage Draw: 125 amps at 3ph 208V
  • The kettle must be grounded
  • PT100 Temp Sender
  • Analog Temp Gauge for quick reading
  • Internal LED Light

HLT Specifications:

  • Grade 304 Stainless Steel
  • Internal Finish: #2B
  • Tank Height: 83"
  • Tank Diameter: 48"
  • Empty Weight: 660 lbs
  • Working Volume: 9 bbl
  • Max Volume: 10.4 bbl
  • All ports are 1.5" TC except for DN350 Manway, DN19 Condensation Pipe, 4" TC CIP Port, 2" TC Element Ports, 4" Welded Vent

Insulated Mash Tun
Our Pro Insulated Mash Tun features slotted 3-piece false bottom, adjustable-height sparge arm, 4" TC port for optional grist hydrator, and a host of other key features guaranteed to satisfy the expectations of today's pro brewer. The mash tun has a slotted plate screen with a large grain out port on the side. The optional hydrator allows you to mix grain with hot liquor if you have your mill or grist case above the mash tun. There is a large top access for manual stirring. The walls of the mash tun are insulated to provide stable mashing temperatures. While intended for a single infusion mash, step mashing can be performed by recirculating through a heat exchanger. The sparge arm is adjustable in height and it is intended to have an inch of water above the grain and have the bottom of the diverted plate resting on top of the grain for low oxygen pickup during recirculating and sparging. We recommend that you use a grant to avoid creating suction on the bottom of the mash screen. It is possible to pull 23,000 lbs of force on the screen with a pump and a fully stuck mash and even partial vacuums can produce significant force. Alternatively, you can install a vacuum breaker ahead of the pump. Replacement screens are available for special order.

Mash Tun Features:
  • Insulated for low heat loss
  • Slotted 3 pieces false bottom
  • Large side grain out door
  • Removable grain out chute
  • 4" TC grain inlet port for optional grist hydrator
  • Adjustable Height Sparge Arm for better HSA performance
  • Sparge Arm has two inlets, HLT and Recirculation.
  • Large top lid for easy stirring
  • PT100 Probe
  • Analog Temp Gauge
  • 450+ lbs Grain Capacity
  • Internal LED Light
  • A 115V Circuit is required for the Mash Rake

Notes Regarding Mash Rake & Plow System

  • The motor comes un-wired. We recommend having an electrician install a reversing motor control in a remote location
  • Raise the plow blade before mashing
  • When it is time to grain out the blade is released onto the top of the mash and allowed to scrape from the top down to the false bottom
  • The rakes are reversed for mashing out
  • The CIP back flush under the screens is accessed by pumping into the inner ring under the mash. This should be closed while mashing
  • The center pipe and outer ring are for wort collection and should be connected to the wort receiver
  • There is a wort return port for recirculation
  • There is a non-adjustable sparge ring for sparge/lauter
  • For more information regarding setup, click here.

Mash Tun Specifications:

  • Grade 304 Stainless Steel
  • Internal Finish: #2B
  • Tank Height: 59"
  • Height w/ Hydrator: 75"
  • Tank Diameter: 50"
  • Empty Weight: 925 lbs
  • Working Volume: 7 bbl
  • Max Volume: 9 bbl
  • Manway: 20.8" x 16.9"
  • All ports are 1.5" TC except for 4" TC Sparge Arm Port, 4" TC Grist Hydrator Port, DN80 LED Light Port

Please note: the primary image shows the mash tun with optional grist hydrator (sold separately).

Power requirements listed represent actual amperage draw.  Please consult a licensed electrician to determine what amperage breaker is required based on your local codes.

Please Note: This item requires a professional electrician for installation.

Please Contact our Customer Service department at 1-800-600-0033 to assess shipment costs and place an order.



Item # PBE0007RP-MB
Weight 2293 LBS
